Choose low-carbon and enjoy a high-quality life
Module | Item | HPC-1000 | HPC-2000 | HPC-3000 | HPC-4000 | HPC-5000 |
Energy Storage System(ESS) | ||||||
(optional) |
Inverter qty. | 1 set | 2 sets | 3 sets | ||
PV maximum input power | 11kW | 11kW*2 | 11kW*3 | |||
Rated input and output power | 10kW | 10kW*2 | 10kW*3 | |||
Mains input and output voltage | 230/380VAC,50/60Hz | |||||
Battery voltage | 40-60VDC | |||||
Lithium-ion battery type | LiFePO4 | |||||
Lithium-ion battery rated capacity | 0-30kWh | 0-60kWh | 0-90kWh | |||
Hydrogen Production and Power Generation Module | ||||||
Electrolyser (AEM) | ||||||
Rated hydrogen production rate | 0.5Nm³/h | 0.5Nm³/h | 1Nm³/h | 1.5Nm³/h | 2Nm³/h | |
Output pressure | Up to 35 bar | |||||
Auxiliary electrolyte | 1% KOH solution | |||||
Nominal power consumption | 4.8kWh/Nm³ (beginning of life) | |||||
Hydrogen output purity(%) | >99.99% | |||||
Fuel Cell(PEMFC) | ||||||
Fuel cell stack cooling | Water cooling | |||||
Fuel cell rated power | 10kW | |||||
Fuel cell system efficiency(%) | ≥85%,and the operating temperature is 60-75°C | |||||
Control voltage | 48VDC | |||||
Fuel cell hydrogen input(%) | >99.97%,6-10bar | |||||
Hydrogen Storage System(HSS) | ||||||
Hydrogen storage tank | Single tank:110L,working pressure 350 bar,20 tanks per group | |||||
Equivalent electricity capacity | 1 group, 1000kWh | 2 groups, 2000kWh | 3 groups, 3000kWh | 4 groups, 4000kWh | 5 groups, 5000kWh | |
Compressor working pressure | 350 bar | |||||
Power input | 220VAC/50Hz/1.5kW | |||||
Buffer tank | 4x70L,with the maximum working pressure of 200 bar | |||||
Heat Pump | ||||||
FloorHeating | Radiator Heating | Cooling | ||||
Ambient temperature(DB/WB) | 7℃/6℃ | 7℃/6℃ | 35℃/- | |||
Water temperature (water inlet/outlet) | 30℃/35℃ | 50℃/55℃ | 12℃/7℃ | |||
Heating | 2.50-6.95kW | 2.00-5.80kW | 1.20-4.50kW | |||
Input power | 0.41-1.48kW | 0.43-1.86kW | 0.26-1.55kW | |||
COP | 6.10-4.68 | 4.63-3.11 | 4.62-2.90 | |||
Power supply | 220-240V/1PH/50Hz |
Hydrogen Production and Power Generation Module | ||
Dimension | (LxWxH)1340x1100x2180mm | |
Weight | 0.8ton |
Hydrogen Storage System(HSS) | ||
Dimension | (LxWxH)2034x1725x2205mm | |
Equivalent electricity capacity | 1000kWh(HPC1000) |
Application Scenario 1:Hydrogen Energy Showroom-“Zero-carbon emission” cottage
Hydrogen Power Cube Model |
HPC1000-0010 (0.5Nm /h) |
|
Heat Pump Model | KSBZ-7D/2A Heating 2.50 6.95kW Hot water 1.03m /h Cooling 1.20 4.50kW |
Energy Storage System (ESS) & Hydrogen Production and Power Generation Module |
Hydrogen Storage System (HSS) |
Heat Pump |
Hydrogen Power Cube Model |
HPC1000-T020 (2Nm /h) |
|
Lithium-ion Battery | 30kWh x 3 |
Hydrogen Production and Power Generation Module |
Hydrogen Storage System (HSS) |
Energy Storage System (ESS) |
