CSB300
300W Fuel Cell System（CSB300）
CBS300 is a power generation system using air-cooled fuel cells,built-in 48V/10 A lithium-ion battery.It has features of intelligent monitoring,small size, light weight,low noise,and environmental friendly.It can be applied to hydrogen energy two-wheeled vehicles,hydrogen energy mobile power and many other scenarios.
CBS300 is a power generation system using air-cooled fuel cells,built-in 48V/10 A lithium-ion battery.It has features of intelligent monitoring,small size, light weight,low noise,and environmental friendly.It can be applied to hydrogen energy two-wheeled vehicles,hydrogen energy mobile power and many other scenarios.
System Working Principle
| Rated output | 300W |
| Rated voltage | 48V |
| Rated current | 10A |
| Rated voltage range | 36~54V |
| Max. power output | 1440W@30s |
| Starting time | ＜20s@936W |
| Overload time | ＞1min@936W |
| Efficiency | ≥40%@Rated power |
| Duration of system operation | ≥2h@400W |
| Dimensions | (L×W×H)276×230×480mm |
| Weight | 16kg（Oxygen cylinder included） |
| Reported data | Equipment online status,hydrogen concentration,location information,lithium-ion SOC,remaining hydrogen |
